The INTCERA 100G QSFP28 PSM4 Silicon Photonics (SiP) optical module (GQM-SPO101-SIR4C) supports transmission distance up to 2km using 1310nm wavelengths. Designed for 100G Ethernet PSM4 links over multiple multimode fibers.
Features:
● Hot-pluggable QSFP28 form factor
● Compliant with QSFP MSA standard
● Compliant with 100G PSM4 MSA standard
● 4 channels full-duplex transceiver module
● Supports 100Gb/s aggregate bit rate
● Silicon Photonics
● 3.5W maximum power dissipation
● Maximum link length of 2km on SMF
● Single MTP/MPO receptacle
● Operating case temperature range: 0 to 70°C
● Single 3.3V power supply
● RoHS-6 compliant (lead free)
Application:
● 100GE direct interconnection
● 100GE to 4x 25GE breakout interconnection
