• 100G SFP-DD AOC

100G SFP-DD AOC

Designed for 100G Ethernet 100GBASE-SR2 direct interconnects over multiple 850nm multimode fibers.

Product description

Features:

● Supports 100Gb/s aggregate bit rate
● 2 channels 850nm VCSEL array
● 2 channels PIN photo detector array
● Internal CDR circuits on both receiver and transmitter channels
● Supports CDR bypass
● 1.5W maximum power dissipation per end
● Maximum link length of 70m on OM3 MMF or 100m on OM4 MMF
● QSFP28 MSA-compliant high-density connectors
● Operating case temperature range: 0 to 70°C
● Single 3.3V power supply
● RoHS-6 compliant (lead free)

Application:

● IEEE 802.3cd 100GBASE-SR2
